Details Description
The MQS-9C1ED01-01 is an SPDT micro snap action switch with a waterproof function, which its rating is 100mA 30VDC and 10mA 14VDC. Meanwhile, this is also a long-life switch because the mechanical life of this model is 500,000 cycles(Mini). And the housing UL94 HB
Besides, the MQS-9C series is also can be used in the electric power tool and automotive parts. Which is endorsed by customers from all over the world.
What’s more, the series has many different parameters for options. For more details, welcome to contact us freely.
Specification
| Electrical Rating | 10~50mA 12~24 VDC 250,000 cycles Min. |
| Operating Temp | -40℃ to +85℃ |
| Mechanical Life | 500,000 cycles Min. |
| Contact Resistance | 50mΩ Max. (initial) |
| Operating Force | 150gf Max. |
| Insulation Resistance | 100ΩM Min. |
| Dielectric Strength | 500VAC for 60 ± 5 sec. |
| Housing: | UL 94 HB Thermoplastic (Base) UL 94 HB Thermoplastic (Cover) |
